O'Gorman Computer Consultants Ltd
Aubit 4GL Documentation
Revision 24-7-14

1 News as at 24 July 2010

Added some new fragments which will be included soon into the manual. Topics:

These are in 3 separate small files for you perusal (and translation into Spanish when finalised). See below.

1.1 Manual for Aubit4GL v1.2

Work is under way. The new manual has been renamed: a4glman

While the full manual is being prepared, I will be putting additions such as Web Services and the New GUI stuff on this website as separate files.

We have a group of volunteers standing by to translate the manual into Spanish. I'm sure they would welcome more volunteers to share the workload. Write to the Aubit4GL user group if you are able and willing to assist.

A few significant chapters have been added:

You can download these (by right-clicking on the URLs) but be warned that they are still in the early draft stages.

There is also documentation of new tools:

and extensions to the 4GL syntax including:

1.2 New Quick Reference

1.2.1 Makefile entries for the Quick Reference


booklet: a4glqref.lyx
     lyx -e ps $?
     psbook $? | psnup -2up > $@

     lp -d OfficeJet-7400 \
        -o Duplex=DuplexTumble \
        -o media=a4 \

The above assume that you have the prerequisite LYX and psutils packages installed.

If not use zypper install or apt-get install (depending on your flavour of Linux) to install both of them

I particularly recommend LYX which is the best piece of software ever written. (It allows you to produce Knuth's beautiful documents without the need to learn the LATEX and TEX languages for professional quality typesetting).

2 Printing

I have had to do a lot of research into printing. Being a die-hard command line man, I wanted to know how to set duplex, short-side flip, landscape modes on the printer form the lp or lpr commands. man lp was totally uninformative. I found the answers in 2, for me, unexpected places: and http://localhost:631.

From the latter you can find the approprate -o options for each of your printers. Under CUPS there is a set of generic commandline options (e.g. -o landscape ) which will be translated into the appropriate command for your printer's language. Anything not recognised as a standard option by the CUPS program is passed through as is (e.g. -o Duplex=DuplexNoTumble).

To find the specific options for your printer, use the command: lpoptions printer where printer is the name of your print queue (inkjet in my case). Then you can print from the command line using the options you want:

lp -d printer -o option1 [-o option2 ...]

For the Aubit 4GL Quick Reference booklet, the command will be something like:

lp -d inkjet -o sides=two-sided-short-edge -o media=a4

You may or may not need to use the option -o landscape. The psbook command puts the content into landscape so the printer may not need it. Try it and see. If it is wrong, it will cost you only 2 sheets of paper.

3 Aubit 4GL Quick Reference

Right click on the links above to download the file(s)

4 Aubit 4GL Manual pages

This is still the old Manual.

4.1 LYX Source of the old Aubit 4GL Manual

This has not been updated yet!


The manual is written using LYX (which has an ASCII format). LYX comes out of the box with SuSE. You can generate the Postscript, PDF, and HTML formats by running LYX and using the File->export option. For those of you without LYX we have the other formats here (or you can view the HTML online).

4.2 Generated Formats:

  1. Current DVI (TEX Device Independent) aubman.dvi:aubit4gl/aubman.dvi
  2. Current PDF (Portable Document Format) aubman.pdf: aubit4gl/aubman.pdf
  3. HTML tree 1 node per chapter:

4.3 Revision List

4.4 Source Tarballs

4.5 latex2html problems

Ross Moore (Maths dept, McQuarrie University) had fixed the bug in latex2html which was bodging tables. Unfortunately this fix was not carried through into current Linux distros. The fix is quite simple and the patch is available here.

The latex2html program is a perl script. The patch needed is:

-- latex2html 2006-01-13 17:48:27.000000000 +1300

+++ /usr/bin/latex2html 2005-03-23 06:49:49.000000000 +1200

@@ -5285,7 +5285,6 @@
    elsif ($this_cmd) { push(@pieces, $this_cmd) }
   push(@pieces, $after);
+  $within_preamble=0;
  print " $replacements new-command replacements\n"

  if (($VERBOSITY>1) && $replacements);

The line prefixed with the + must be inserted into the latex2html script.
